DESCRIPTION

Overview

Basic Info.

Model NO.	22322
Payment	Tt
Price	Reasonable
Quality	Good
OEM	Accept
Delivery	3-5 Days
Transport Package	OEM
Specification	oem
Trademark	oem
Origin	China
HS Code	8482100000
Production Capacity	10000

Product Description

Product Description

Self-aligning roller bearing:

This bearings have barrel-shaped rollers between the inner ring, which has two raceways, and the outer ring which has one spherical raceway. Since the center of curvature of the outer ring raceway surface coincides with the bearing axis, they are self-aligning in a manner similar to that of self-aligning ball bearings. Therefore, if there is deflection of the shaft or housing or misalignment of their axes, it is automatically corrected so excessive force is not applied to the bearings.

Spherical roller bearings can take, not only heavy radial loads, but also some axial loads in either direction. They have excellent radial load-carrying capacity and are suitable for use where there are heavy or impact loads.

Features:

1,Spherical roller bearings can take, not only heavy radial loads, but also some axial loads in either direction. They have excellent radial load-carrying capacity and are suitable for use where there are heavy or impact loads.

2,Some berings have tapered bores and may be mounted directly on tapered shafts or cylingrical shafts using adapters or withdrawal sleeves.

3,Pressed steel and machined brass cages are used.

Main Export Markets:

• Eastern Europe
• North America
• Mid East/Africa
• Central/South America
• Asia
• Western Europe
• Australasia

Quality Control:

We make all the beating according to the quality standard of ISO9001:2008 and ASME. We have our own in-house lab to test the material and bearing. Our strict testing and inspection system guarantee the high hardness, high abrasion and high temperature resistance, Before delivery, there will be a final and extra quality confirmation to ensure all the beatings in good order and condition .The quality of our products is good enough and they are warmly welcomed by many customers.

Related models

Specification		Boundary dimensions(mm)			Mass(kg)	Specification		Boundary dimensions(mm)			Mass(kg)
Cylindrical Bore	Tapered Bore	d	D	B		Cylindrical Bore	Tapered Bore	d	D	B
22205	22205K	25	52	18	0.16	22334	22334K	170	360	120	57.9
22206	22206K	30	62	20	0.26	22336	22336K	180	380	126	67.5
22207	22207K	35	72	23	0.39	22338	22338K	190	400	132	78.1
22208	22208K	40	80	23	0.48	23022	23022K	110	170	45	3.75
22209	22209K	45	85	23	0.53	23024	23024K	120	180	46	4.11
22210	22210K	50	90	23	0.57	23026	23026K	130	200	52	5.99
22211	22211K	55	100	25	0.76	23028	23028K	140	210	53	6.52
22212	22212K	60	110	28	1.04	23030	23030K	150	225	56	7.9
22213	22213K	65	120	31	1.43	23032	23032K	160	240	60	9.66
22214	22214K	70	125	31	1.51	23034	23034K	170	260	67	13
22215	22215K	75	130	31	1.59	23036	23036K	180	280	74	17.1
22216	22216K	80	140	33	1.93	23038	23038K	190	290	75	17.6
22217	22217K	85	150	36	2.41	23040	23040K	200	310	82	22.4
22218	22218K	90	160	40	3.11	23122	23122K	110	180	56	5.7
22219	22219K	95	170	43	3.82	23124	23124K	120	200	62	7.84
22220	22220K	100	180	46	4.62	23126	23126K	130	210	64	8.68
22222	22222K	110	200	53	6.78	23128	23128K	140	225	68	10.5
22224	22224K	120	215	58	8.45	23130	23130K	150	250	80	15.8
22226	22226K	130	230	64	10.5	23132	23132K	160	270	86	20.3
22228	22228K	140	250	68	14.5	23134	23134K	170	280	88	21.8
22230	22230K	150	270	73	18.4	23136	23136K	180	300	96	27.5
22232	22232K	160	290	80	23.2	23138	23138K	190	320	104	34.5
22234	22234K	170	310	86	28.9	23140	23140K	200	340	112	42.6
22236	22236K	180	320	86	30.2	23218	23218K	90	160	52.4	4.52
22238	22238K	190	340	92	35.5	23220	23220K	100	180	60.3	6.6
22240	22240K	200	360	98	42.7	23222	23222K	110	200	69.8	9.54
22308	22308K	40	90	33	0.96	23224	23224K	120	215	76	12.1
22309	22309K	45	100	36	1.28	23226	23226K	130	230	80	14.3
22310	22310K	50	110	40	1.67	23228	23228K	140	250	88	18.8
22311	22311K	55	120	43	2.19	23230	23230K	150	270	96	24.2
22312	22312K	60	130	46	2.72	23232	23232K	160	290	104	30.5
22313	22313K	65	140	48	3.34	23234	23234K	170	310	110	36.4
22314	22314K	70	150	51	4.04	23236	23236K	180	320	112	38.9
22315	22315K	75	160	55	4.96	23238	23238K	190	340	120	47.6
22316	22316K	80	170	58	5.91	23240	23240K	200	360	128	57.1
22317	22317K	85	180	60	6.72	24024	24024K	120	180	60	5.33
22318	22318K	90	190	64	8.06	24026	24026K	130	200	69	7.84
22319	22319K	95	200	67	9.3	24028	24028K	140	210	69	8.37
22320	22320K	100	215	73	12.2	24030	24030K	150	225	75	10.5
22322	22322K	110	240	80	17	24032	24032K	160	240	80	12.7

Detailed Photos

Factory view

Company Profile

Anchi hardware CO.,LTD is a professional bearing manufacturer and dealer in China.We have been engaged in bearing industry for 20 years and made international trade of bearing import and export for more than 10 years.

Our company is specialized in ball bearing,roller bearing.Also we can customize various large non-standard products such as the most competitive products according to customers' demands.

Advantage of our company

1. More than 10 years industry experience

2. Our own brand LBR

3. Accept OEM, customization, customers' logo

4. 7/24 hours calling service

5. Reply your inquiry within 12 hours

6. Professional technical support

7. Good ability of cost control brings you reasonable price, long-term partner of forwarder brings you low freight

8. Special discount and protection of sales area provide to our distributors

FAQ

Q:What kind of bearing do you produce?

A:ball bearing and roller bearing .

Q:Can we print our own brand on the bearings?

A: yes, you can. You can contact with the salesman for detail information.

Q: what is the package?

A: Plastic tube and single color box package.We can also accept your own color box design.

Q:What is the delivery?

A:3-5 days,of course it based on the quantity of you order.

Q:What is the payment?

A:Usually we accept T/T,we also can accept RMB .
